Silicone Rubber Insulation Self-fusing Tape
The Self-Fusing Silicone Rubber Insulation Tape is a new insulation material, avoid bare conductors short circuit or tripping because of the wild animal or human contact it. Prior to use, simply tear the isolation layer, and then stretched under moderate shiplap wrapped on the Busbar and Conductor to be protected by certain conditions, can self-park after tightening fused into one, with electrical insulation, heat, moisture, sealing function, used in electronics, telecommunications, electrical, construction and other fields.

Main Features of Silicone Rubber Self fusing Tape:


1. Easy to use, no auxiliary materials;
2. Dielectric strength test 19.7 kV / mm;
3. Environment-friendly;
4. Moisture sealing, good thermal conductivity;
5. Can be customized;
6. Anti-aging, acid salt and UV, not falling, stable performance.

Technical Data of Silicone Insulation Tape:

1. Material: Silicone Rubber
2. Width (mm): 20/50
3. Thickness (mm): 0.5/0.8/1.0
4. Length (m): 5
5. Tensile Strength: 6.5 MPa
6. Elongation at Break: 600%
7. Flame Retardant: FV-0

Application Scope of Self Fusing Silicone Rubber Electrical Tape:

1. Bus-bar;
2. Bare Wire;
3. Switchgear Cabinet;
4. Bar-bar Connection;
5. Other

Contact us get more details about Self-Fusing Silicone Rubber Insulation Tape, such as TDS, Application Method, OEM etc.

We can supply different color & size of Self-Fusing Silicone Rubber Insulation Tape, such as such as color, size, also customer required.
